Overview

The ‘Chauvet ILS Command Package 1’ contains:

• X1 Chauvet GigBar Move + ILS
• X1 Chauvet ILS Command

Chauvet GigBar Move + ILS

The future of easy lighting synchronization is here with GigBAR Move + ILS. This powerful member of the GigBAR family controls the Integrated Lighting System (ILS), the dynamic lighting technology that provides an advanced, coordinated light show across multiple fixture types. GigBAR Move + ILS can control any ILS-enabled fixture, wired or wirelessly. GigBAR Move + ILS is a 5-in-1 lighting system that includes moving heads, derbies, washes, a laser and strobe effect pre-mounted on a single bar. Easy navigation and access to all the powerful 32-watt moving head functions can be accessed directly from the full-color LCD display and Totem Mode keeps the moving heads focused on the dance floor. Built-in UV LEDs illuminate florescent objects for dazzling blacklight effects. GigBAR Move + ILS gives you individual control of each effect to ensure your show looks the way you need it to, but gone is the need to aim a remote directly at the unit! The included RF remote triggers built-in shows without needing line of sight operation. Other easy control options include stand-alone mode, DMX, or wireless footswitch. The GigBAR Move + ILS package includes a tripod, wireless footswitch, RF remote and FREE carry bags to ensure quick setup.

Chauvet ILS Command

Light up the night without setting up all day with the Chauvet ILS Command – the Integrated Lighting System that makes creating a synchronized light show across different fixture types fast and easy without DMX. Now the ILS universe is at your command with ILS Command, a powerful controller capable of programing any ILS–enabled product. This hardware controller has a built–in D–Fi transmitter that wirelessly controls an unlimited number of ILS–enabled fixtures. Enjoy unlimited creativity as you customize, save and recall presets even in dark environments where backlit silicon buttons provide a tactile response and bright visibility. Your lighting creations are always safe because you can back up, restore and update the controller’s software using the built–in USB port and ensure unauthorized access is blocked by enabling the onboard lockout. An innovative follow spot mode highlights grand entrances without interrupting the rest of the show and a built–in audio connector allows for better accuracy when triggering lights to the beat. Manually override the show on the fly using the 9 quick color access buttons. Safely transport the controller with the included carry case.

Features

Product Specifications

Chauvet GigBar Move + ILS

• DMX Channels: 3, 28, or 50
• DMX Connectors: 3-pin XLR
• Pan and Tilt: 540°/180°
• Colors:
  (moving head): 9 + open, split colors, continuous scroll at variable speeds
• Gobos:
  (moving head): 9 + open, continuous scroll at variable speeds
• Light Source:
  (pars): 3 LEDs (hex color RGBAW+UV) 6 W (2 A), 50,000 hours life expectancy
  (strobe): 4 LEDs (cool white) 5 W (1.2 A), 50,000 hours life expectancy
  (derby): 8 LEDs (2 red, 2 green, 2 blue, 2 white) 6.5 W (2 A), 50,000 hours life expectancy
  (moving head) 1 LED (cool white) 32 W, (3 A), 50,000 hours life expectancy
  (Laser) 638 nm/30mW (red) laser diode, 520 nm/20 mW (green) laser diode, 450 nm/ 50 mW (blue) laser diode
• Strobe Rate: 0 to 30 Hz
• Beam Angle:
  (moving head): 17°
  (pars): 22°
  (strobe): 30°
• Field Angle:
  (pars): 33°
  (strobe): 62°
• Coverage Angle:
  (derby): 131°
  (laser): 93°
• Fits Tripod Size: 1.5 in (37.4 mm)
• Illuminance:
  (pars): 1,205 lux @ 2 m (per par)
  (moving head): 5,140 lux @ 2 m (per head)
  (strobe): 130 lux @ 2 m
• Power Linking: 7 units @ 120 V; 12 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:
  81 W, 1.1 A @ 120 V, 60 Hz
  79 W, 0.6 A @ 230 V, 50 Hz
  248 W, 1.8 A @ 230 V, 50 Hz
• Weight: (bar only) 31 lbs (14 kg)
• Size: 43 x 5.7 x 17.7 in (1100 x 144 x 449 mm)
• Approvals: CE, UKCA, RoHS, FCC, FDA
• Stand Height: 4.8 ft to 8.3 ft (1.5 to 2.5 m)
• Footswitch Operating Frequency: 433 MHz
• Footswitch Max Unobstructed Distance: 100 ft (30.5 m)
• Footswitch Battery: 9 V alkaline
• Included Controllers: RF remote, wireless footswitch
• Cable Length: 10 ft (3 m)
• Tripod Thickness: 1.37 in (35 mm)
• Optional Controllers: RF

Chauvet ILS Command

• ILS Connectors: 3-pin XLR
• Programmable Presets: 6
• Operating Frequency: 2.412 to 2.484 GHz
• Cable Length: 20 in (508 mm)
• Max Unobstructed Distance: 600 ft (183 m)
• Input Voltage (USB-C): 5V, 1A
• Weight: 3.6 lb (1.6 kg)
• Size: 12.3 x 9.9 x 0.7 in (313 x 252 x 19 mm)
• Approvals: CE, UKCA, RoHS, FCC
