The Electro-Voice Evolve 30M-W Portable Column System is designed to deliver a significant step up in all around performance for a column system in its size/price category – superior Electro-Voice sound quality and flexible functionality combined in a very compact package.
It is equipped with the most complete feature set in its class, including an eight-channel digital mixer, studio-quality onboard effects, and remote control of all audio, effects and mix functions via the next-generation Electro-Voice QuickSmart Mobile application.
SUPERIOR ELECTRO-VOICE SOUND QUALITY AND FLEXIBLE
FUNCTIONALITY – COMBINED IN A VERY COMPACT PACKAGE
The Electro-Voice Evolve 30M is designed to deliver a significant step up in all-around performance for a column system in its size/price category. It is equipped with the most complete feature set in its class, including an eight-channel digital mixer, studio-quality onboard effects, and remote control of all audio, effects and mix functions via the next generation Electro-Voice QuickSmart Mobile application.
High-resolution, low-latency Bluetooth* streaming ensures excellent results for music playback or accompaniment.
REFINED INDUSTRIAL DESIGN AND PROFESSIONAL-GRADE
The Electro-Voice Evolve 30M-W Portable Column System sounds as good as it looks. The full-range column array and its six lightweight 2.8” neodymium drivers provide ultra-wide 120° coverage via proprietary waveguides;
array-formed 40° asymmetrical vertical coverage ensures acoustic output is directed towards both sitting and standing audience members. A 10” subwoofer is housed in a 15 mm wood enclosure for enhanced rigidity and acoustical performance. A Class-D amplifier provides up to 1000 W of output power. The array and sub are connected via a two-piece symmetrical aluminum pole with internal wiring and magnetically assisted latching.
INDUSTRY-LEADING QUICKSMART DSP
QuickSmart DSP allows navigation of system parameters via an LCD with single-knob control or via the app, as well as multiple options for signal routing and inputs. Functions include four presets (Music, Live, Speech, Club), three-band system EQ (low, mid, high), seven-band graphic EQ (in Mixer mode), five user-programmable presets (Store and Recall settings), phantom
power, visual monitoring of limiter status, input level control and meters, and a master volume control to optimize gain structure.
ONBOARD MIXER GIVES YOU BEST-IN-CLASS CONNECTIVITY AND CONTROL
Developed in collaboration with the world-class audio electronics engineering team at EV’s sibling brand Dynacord, the integrated fully featured, fully configurable digital mixer has multiple inputs with professional-grade preamps and mix functions. The mixer can be controlled via the QuickSmart
Mobile app or via the LCD/single-knob interface.
FINESSE YOUR SOUND WITH MUSICIAN-FRIENDLY FEATURES
Independent channel aux sends and Hi-Z and foot switch inputs are included for flexible system configuration, and a range of onboard studio-quality effects (30 presets, including chorus, delay, flange and reverb, via two FX channels) add myriad options for musicians to fine-tune their tone – and reduce the amount of gear they need to bring to the gig. The onboard effects can be controlled via the QuickSmart Mobile app or via the LCD/single-knob interface.
The EVOLVE 30M joins the larger EVOLVE 50 in the award winning Electro-Voice EVOLVE column speaker system series.
Frequency response (-3 dB) : 51 Hz – 20 KHz
Frequency range (-10 dB) : 45 Hz – 20 KHz
Maximum SPL2 : 123 dB
Coverage (H x V): 120° x 40°
Amplifier rating: 1000 W
LF channel rating: 500 W
HF channel rating: 500 W
Crossover frequency: 200 Hz
Connectors: 4x XLR/TRS combo jack line/mic input
2x XLR/TRS combo jack for stereo line input
1x 1/4” TRS Hi-Z input
1x stereo RCA input
1x 3.5 mm stereo input
1x wireless stereo Bluetooth® audio input
1x 1/4” foot switch input
1x XLR mix out output
1x XLR aux out output
Enclosure: Column: composite
Pole (2 pcs): aluminum
Sub: 15 mm plywood
Grille: Steel with black or white powder coat
Color: Black or white
Dimensions (HxWxD): mm (in) Column: 620 x 95 x 157 (24.4 x 3.7 x 6.2)
Pole (2 pcs): 600 x 48 x 55 (23.6 x 1.9 x 2.2)
Sub: 448 x 332 x 432 (17.6 x 13.1 x 17)
Net weight: Column: 6.0 lb (2.7 kg)
Pole (2 pcs): 3.1 lb (1.4 kg)
Sub: 34.9 lb (15.8 kg)
Bag for column and pole: 1.9 lb (0.85 kg
