HEDD Type 07 MK2 Black Studio Monitor Package

£1,729.00

Stock expected mid-June

Implemented in the HEDD Type 07 MK2 Black Studio Monitor 2-Way, 2X100W W/ DSP is the HEDD Lineariser®, a phase linearisation tool that leads to perfect impulse responses and an audibly improved spatial reproduction.

Description

The HEDD Type 07 MK2 Black Studio Monitor Package includes:

HEDD Type 07 MK2 Black Studio Monitor 2-Way, 2X100W W/ DSP

HEDD are thrilled to announce a brand-new series of professional active loudspeakers including the HEDD Type 07 MK2 Black Studio Monitor 2-Way, 2X100W W/ DSP (Single). The new range includes TYPE 05 MK2, TYPE 07 MK2, TYPE 20 MK2, and TYPE 30 MK2 models and, as a first, our powerful BASS 08 and BASS 12 subwoofers. the loudspeakers are handcrafted in Berlin Germany.

ON-BOARD LINEARISER®

Implemented in the MK2 and subwoofer models is our well-known Lineariser®, a phase linearisation tool that leads to perfect impulse response and an audibly improved spatial reproduction.

The MK2 Monitors have a new and improved lacquer for higher durability and better looks. The monitors will also be available in white.

COP TECHNOLOGY

Users for the first time can choose between the energy and bass-capacities of a modern bass-port design and the painstaking precision and control of a closed cabinet approach. Removable plugs for the bass reflex tubes, together with accordingly designed filter set ups allow optimum results in either mode.

PHASE LINEAR SUB-SATELLITE SYSTEM

We are introducing a completely phase linear Sat-Sub system. These are the first Satellite Sub systems that are completely “…right in time” by combining a phase linearized subwoofer with a correspondingly time delayed (group delayed) satellite output. Additionally the listener can compensate eventual distances between subwoofers and satellites to stay with linear phase reproduction for the complete system.

SUBWOOFERS

In addition to the new studio monitor models, we debut two powerful and equally unique subwoofers called BASS 08 (8“ woofer) and BASS 12 (12“ woofer). These subwoofers can be combined with our previous models as well as any other active speaker system. However, their full potential lies in the seamless integration with our new HEDD MK2 models.

FEATURES

  • 2 Year warranty
  • 2 x 100w per speaker
  • 2 Way amplification
  • Active – no amp required
  • Includes removable bass port plugs

SSL2+ USB Audio Interface

The SSL 2+ USB Audio Interface brings together the best of our technology with the right features and expanded I/O capability to get the most out of creating as a team.

Real analogue enhancement inspired by SSL 4000 series (4K) console

SSL has a history of innovation in analogue electronics and console design. Whether it be the sound of our classic EQ ‘242’ and ‘292’ EQ circuits, the punch of the legendary SSL G-Series Bus Compressor or the incredible bandwidth and sonic accuracy of our ground-breaking SuperAnalogue designed mic amps and consoles, we’re always moving forward with analogue.

Legacy 4K is an all-new analogue enhancement effect, inspired by the character of an SSL 4000 series console (often referred to as ‘4K’). With the Legacy 4K button, we’ve distilled 2 essential characteristics of the 4K sound into a single-circuit, which you can engage when you need to breath some life into ‘boring’ or ‘dull’ sounding input sources.

1st characteristic: High-Frequency EQ boost – The first thing engaging the Legacy 4K button will do is introduce a ‘forward’, yet musical high-frequency EQ boost, something which 4000-series EQs are known and loved for.

2nd characteristic: Subtle-Harmonic Distortion – 4K consoles are synonymous with imparting a certain ‘mojo’ to signals passing through them. This mojo comes through multiple stages of harmonic distortion from compressor VCAs, VCA Faders and other crucial areas like the transistor mix amps. Using modern components, we’ve created a circuit that injects a controlled amount of finely-tuned, sweet- sounding harmonic distortion into the signal path, helping to give your sound more edge!

FEATURES

  • 2-In/4-Out USB-C Audio Interface
  • 2 x SSL-designed microphone preamps
  • Legacy 4K – analogue colour enhancement, inspired by classic SSL consoles
  • 2 x Professional, high-current grade headphone outputs: create a second independent headphone mix
  • 24-bit / 192 kHz AD/DA AKM Converters
  • Easy-to-use Monitor Mix Control
  • Balanced monitor outputs
  • Additional unbalanced RCA outputs for easy connection to DJ Mixers
  • MIDI I/O
  • SSL Production Pack software bundle
  • USB 2.0 bus-powered audio interface for Mac/PC

HEDD Type 07 MK2 Black Studio Monitor 2-Way, 2X100W W/ DSP

  • Woofer 7″ (1.5″ voice coil)
  • Tweeter HEDD AMT
  • Crossover frequencies (48 db/oct) 2.300 Hz
  • Inputs XLR
  • Input impedance 22k Ohm
  • Input gain +/- 12 dB
  • Input sensitivity -10 / -4 / 0 / +4 dB
  • Output AES (Through) XLR
  • Lineariser disengageable delay 10ms
  • Shelve filters high/low +/- 4dB
  • LF range normal/extended/satellite 38/30/80 Hz
  • Desk filter small/medium/large 180 Hz (-1/-2/-4 dB)
  • Frequency response (-3 dB) 38-40,000 Hz
  • Max SPL 116 dB
  • AD/DA conversion 96 kHz / 24-Bit
  • Dimensions (W x H x D) 220 x 370 x 300mm
  • Weight 9.9kg

SSL2+ USB Audio Interface

System requirements and Specs:
Mac OS 10.11 and above | Class-Compliant, Plug-and-play
Windows 8.1, Windows 10 | Install included ASIO/WDM driver

Connectivity
USB 2.0 Type C Connector (Box includes Type C to C and Type C to A)

Mic Preamps
-130.5 dBu EIN
Gain Range: 62 dB

Instrument/Line
Max Instrument Input Level: +15 dBu
Max Line Input Level:  +24 dBu
*Specs (Measured to AES17 Standards)

Monitor Outputs
Dynamic Range: 112 dB​
Max Output Level: + 12.5 dBu​

Headphone Output(s)
Dynamic Range: 111 dB
Max Output: +10 dBu

Sample rates​
44.1, 48, 88.2, 96, 176.4, 192 kHz
