Laserworld EL-230RGB MK2


Available to Order.

Estimated delivery: 3-5 working days, join waitlist below.

Multi-color and stunning white light laser with plug & play operation and DMX control projecting in-air beams, waves and tunnel effects. Perfect for creating a fun atmosphere with a range of colors at home parties, small bars, and mobile DJ events.

Join the waitlist to be emailed when this product becomes available

EAN: 7640144991630 Categories: , Brand:



The Laserworld EL-230RGB MK2 is a RGB laser system with a total output power of up to 230 mW.

The red diode laser module with a wavelength of 650 nm, the green DPSS laser module with a wavelength of 532nm and the royal-blue laser module with a wavelength of 445 nm ensure beautiful colors and brightness. The beams have a diameter of about ca. 4 mm and a beam divergence of about 1 mrad and the projector offers high-speed step motors, up to 2-5 kpps as well as a scan angle of up to 30°. About ca. 50 (layers, tunnels, fences, waves, etc.) can be controlled via DMX. A sound-to-light mode as well as a stand-alone mode are available too. For the sound-to-light mode the sensitivity of the integrated adjustable microphone can be adjusted.
There is an interlock connector for safety switch as well as a key switch at the rear side of this very compact device.

The Laserworld EL-230RGB MK2 is a good solution for first-time users and mobile use and it is often used in bars, small clubs, at private parties or for home use.

With ultra bright 445 nm royal blue!

  • Typical power 230 mW
  • 7 colors including white
  • Ca. 50 (layers, tunnels, fences, waves, etc.)
  • Stand-alone mode
  • Sound-to-light mode
  • DMX programmable

Product Specifications

Total Power230 mW
Guaranteed Power170 mW
Power Red100 mW / 650 nm
Power Green20 mW / 532 nm
Power Blue50 mW / 445 nm
Beam Specificationsca. 4 mm / 1 mrad
Scannerhigh-speed step motors, up to 2-5 kpps
Max. Scan Angle30°
Laser SourceDiode, DPSS Laser
Laser Class3B
Operation ModesStand-Alone, Sound-to-Light, DMX
Basic Patternsca. 50 (layers, tunnels, fences, waves, etc.)
Accessoriespower cable, manual, interlock, key
Power Supply85V – 250 V AC
Power Consumption30 W
Dimensions205 x 145 x 75 mm
Weight2.0 kg
